| Measuring medium | Gas, liquid or fluid (compatible with contact materials) |
| Pressure range | -0.1～0～6MPa (see range selection table for details) |
| Pressure mode | Gauge pressure, absolute pressure, negative pressure |
| Medium temperature | -40～85℃ |
| Connection time | 20ms |
| Accuracy level | 0.5%FS (reference conditions: temperature 15-25°C, atmospheric pressure 86-106kPa, humidity 45-75%RH) |
| Stable performance | ±0.2% FS/year |
| Temperature drift | ±0.02%FS/℃ |
| Explosion-proof type | Intrinsically safe Ex ia ⅡC T6 Ga (4～20mA output only) |
| Protection level | IP65 Note: The above protection level refers to the level achieved after the electrical connection is complete. |
| Durable performance | # Lost Data # |
| Response frequency | Analog signal output ≤30Hz Digital signal output ≤5Hz |
| Overall weight | ≈140g |
| Resolution | Analog output 0.02%FS, digital output 0.05%FS |
| Output power supply | |
| 4～20mA | 9～28VDC, 15～24VDC (intrinsically explosion-proof) |
| RS485 | 9～28VDC |
| Maximum Power | |
| 4～20mA | ≤0.02Us(W) |
| RS485 | ≤0.015Us(W) |
| Load characteristics | |
| Current Type | Load ≤{(Us-7.5)÷0.02}Ω |
| Environmental conditions | |
| Ambient temperature | -40～85℃ |
| Ambient humidity | 0%～95%RH (no condensation, no condensation) |
| Overpressure and explosion | |
| Overload pressure | 200%FS, 200%FS, 200%FS, 150%FS, 200%FS, 200%FS |
| Burst pressure | 400%FS, 250%FS, 250%FS, 200%FS, 400%FS, 250%FS |
| Overall material | |
| Diaphragm | Ceramic (contacting the measured medium) |
| Process connection | PVDF polyvinylidene fluoride (contacting the measured medium) |
| shell | 304 Stainless Steel |
| Core seal | See the pressure and burst chart (contact with the measured medium) |
| Hirschmann connector | ABS engineering plastics |
| Mechanical stability | |
| Vibration resistance | 10g (20…2000Hz) in accordance with IEC60068-2-6 standard |
| Impact resistance | 500g/ms Comply with IEC60068-2-27 standard |
| Electrical protection | |
| Short circuit protection | permanent |
| Reverse polarity protection | No damage, but not working |
| Insulation resistance | ≥100MΩ 500VDC |
| Dielectric strength | 500VAC |
| Output Limitation | |
| 4～20mA | 4mA~20mA |
| RS485 | 0~2000 |
